Cortizo 80 CE

Cortizo 80 CE is a carpentry system with exceptional thermal performance that recommends it for passive constructions, with a modern design and very generous maximum manufacturing dimensions.

The system also boasts high ratings in air permeability, water tightness, and wind resistance, making it ideal for harsh climates and energy-efficient buildings

Advantages

  • Available in almost 800 different colors and textures, including imitations of wood and anodizing.
  • The system allows simple and oscillating openings, with European channel hardware.

Certifications

  • CE
  • Qualanod
  • Qualicoat Seaside
  • Quality
  • Qualimarine
  • CSTB
  • Passive house

Technical Characteristics

Depth 3.15 inches
Visible height 3.46 inches
Central node 5.46 inches
Maximum sash dimensions Width (L) 59.06 inches / Height (H) 102.36 inches
Maximum sash weight 352.74 lbs
Maximum glazing thickness 2.56 inches
Thermal performance UW ≥ 0.116 BTU/hr·ft²·°F
Acoustic performance 46 dB

ESA classifications

Air resistance (UNE-EN 12207: 2000) Class 4
Water resistance (UNE-EN 12208: 2000) Class E1950
Wind resistance (UNE-EN 12210: 2000) Class C5
Sample size tested 1,23 × 1,48 m, 2 frames
